240150 BLDC Heavy Lift Drone Motor 220KG Thrust 15KW

Product Categories

Dongguan Furious Technology Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 240150 BLDC Heavy Lift Drone Motor 220KG Thrust 15KW
Brand: Furious Motor
Price: 6 USD

Place of Origin : Guangdong, China

Brand Name : Furious Motor

Model Number : 240150

MOQ : 4

Price : $6,999-7,356

Torque : 234N.m

Speed RPM : 2335

Continuous Current : 92A

Efficiency : 89%

Frame Size : 240mm

Rated Voltage : 0-500V

Rated Power : 15kw

Motor Mounting : Panel Mount

Dimension : 240mm x 150mm

ESC Rating : 400V 160A

Max Voltage : 447V

Peak Current : 153A

Suggested Propeller : 78 inch

Max Thrust : 220KG

Weight : 16Kg

Contact Now

Item	Value
Warranty	3 months
Place of Origin	China
	Guangdong
Brand Name	Furious Motor
Model Number	Zero-G 240150
Usage	Heavy lift drone, cargo drone, multi-rotor drone, paramotor, paraglider, VTOL drone, search and rescue drone.
Type	Brushless Motor
Construction	Permanent Magnet
Commutation	Brushless
Protect Feature	Explosion-proof
Efficiency	89%
Dimension	240mm x 150mm
KV Availability	8 / 15 / 25 / 40
ESC	400V 160A
Max. Torque	234N.m
Max. Thrust	220kg
Max. RPM	2335
Max. Voltage	400V
Peak Current	153A
Continuous Current	92A
Suggested Propeller	78
Configuration	36N20P
Weight	16kg
